1 x HO scale model railroad B&O CPL color position light signal LED metal #U1D1

1 x HO scale model railroad B&O CPL color position light signal LED metal #U1D1

Product Code: WH404340732013
Availability: 100

overview

price for 1 complete signal ( common anode )LEDs mademiddle dial target may show Green/Amber/Red light, upper and lower targets may show warm white.the black wires are Common Anode wires, the color wires are cathode wires. ( message me right after pa...
$27.43
price for 1 complete signal ( common anode )




  • LEDs made
  • middle dial target may show Green/Amber/Red light, upper and lower targets may show warm white.
  • the black wires are Common Anode wires, the color wires are cathode wires. ( message me right after payment if you need Common Cathode signal ), must wire 470 ohm 1/4W resistors with Green LED, warm white LED and 510 ohm 1/4W resistors with Red and Yellow LED if you need the green light shows along with the red or yellow light, or control them with my Master Board.
  • color: black ( default ), or please message me right after payment if you need it in other colors.

Specifications:

  • Brand: WeHonest Model.
  • Size: Please check it from the above photo.
  • Reference Scale: Suitable for OO/HO scale layouts.
  • Operating Voltage: 3V DC only.
  • ( do NOT use it on 12V DC directly, must wire a 620 ohm resistor with the black wire if use on 12V DC )
  • Operating Current for each light: 20mA.
  • Material: steel

Package included:

  • 1 complete common anode signal ( with box )
